Grand Soleil 40
Performance-Cruiser built in 2002Fast, elegant performance cruiser from the heyday of the IMS formula. The Grand Soleil 40 by Duck Design/Massimo Paperini was a very successful racer in the international regatta circus but she is also a comfortable, stiff cruising yacht that can be easily and safely managed by a small crew. The Grand Soleil 40 has a modern hull with sharp vertical bow, wide stern and narrow waterline. The 3 spreader racing mast ensures amazing performance. Spacious, ergonomic deck layout with german mainsheet system and all sheets and trim lines lead aft to the cockpit. Mahogany interior by Patrick Roseo with laminated floorboards.
This Grand Soleil 40 is a racing version with racing keel (draft: approx. 2,40 m), 3 spreader racing rig with standing rigging in rod as well as HARKEN racing deckgear (high-quality racing deck fittings). The hull is wrapped in light grey. 3 cabin layout with owner's cabin forward, two symmetric aft cabins and one heads compartment. Engine upgrade to YANMAR 40 hp. Nice, good looking yacht with light grey hull, black sripes and light grey trim on coachhouse sides.
Key Facts
- Hull wrapped in light grey.
- 3 spreader racing rig.
- Exiting performance.
- Racing keel (draft: 2,40 m).
- HARKEN racing deck gear.
- 3 cabin layout.
Main Info
| Model | Grand Soleil 40 |
|---|---|
| Manufacturer | Cantiere del Pardo (ITA) |
| Designer | Duck Design/Paperini |
| Category | Performance-Cruiser |
| Year | 2002 |
| Location | Adria/Kroatien |
| Flag | Austria |
|---|---|
| VAT status | excl. VAT |
| Material | GRP |
| Rig | Sloop |
| Cabins | 3 |
| Berths | 6 |
Dimensions & Technical details
| Length | 12.19 m |
|---|---|
| Length waterline | 10.60 m |
| Beam | 3.80 m |
| Draft | 2.40 m |
| Displacement | 6.8 t |
| Sail area | 102 m² |
| Engine | YANMAR 3JH3E |
|---|---|
| Power | 40 PS/29 KW |
| Drive | Saildrive with folding propeller |
| Fresh water | 360 L |
| Fuel | 180 L |
Grand Soleil 40 | Performance-Cruiser built in 2002
Specification
Rigging/Sails
- Keel stepped, 9/10 fractional SPARCRAFT performance mast
- Three pairs of aft swept spreaders
- Standing rigging in rod rig
- HARKEN genoa furling system with removable drum
- Hydraulic backstay tensioner NAVTEC
- Spinnaker pole
- Spinnaker/gennaker gear
- Mainsail SUPREME-Sails laminate triradial
- Forling genoa SUPREME-Sails laminate triradial
- Spinnaker
Deck
- Teak deck on cockpit seats and swim platform
- HARKEN racing deck gear
- Long HARKEN genoa tracks with ball-bearing, line-adjustable genoa cars
- Wide HARKEN mainsheet traveller
- German mainsheet system with mainsheet winches HARKEN 44.2STC
- Genoa winches HARKEN 48.2STC
- halyard winches HARKEN 44.2STC
- Electric anchor windlass QUICK
- Mooring gear: Stainless steel DELTA-anchor 15 kg with 30 m stainless steel anchor chain 8 mm
- Large, self-draining anchor locker
- Two Dorade vents on coachhouse roof
- Swim ladder
- Cockpit shower
- Spring cleats
- Storage lockers below cockpit seats
- Additional deck lockers in cockpit to starboard below helmsman's seat
- Outboard engine bracket on pushpit
Layout/Interior
- Grand Soleil 40 in 3 cabin layout with owner's cabin forward
- Saloon with U-shaped dinette to starboard and central sliding bench seat at saloon table
- Longitudinal galley to port
- Worktop in white CORIAN
- Gas stove (2 burners and oven)
- Double sink
- Additional manual foot pump
- Large electric cool box - Forward fasing chart table fitted to starboard aft
- Forward owner's cabin with wide island double berth, lockers, shelves, storage space below berth and three deck hatches
- Heads compartment to port aft
- Two symmetric guest cabins aft with double berth, locker, deck hatch and porthole
- Mahogany interior
Technical Equipment
- YANMAR 3JH3E 3 cylinder inboard diesel 40 hp/29 KW (engine upgrade)
- Engine hours (as of October 2022): 2.287 h
- Saildrive with 3 blade folding propeller Flex-o-Fold (new 2018)
- Stainless steel diesel tank approx. 180 l
- 230 V shore power connection with 230 V sockets below decks
- Battery charger QUICK 12 V/60 A
- 3 x service battery 12 V/98 Ah
- Starter battery 12 V/80 Ah
Safety
- Fire extinguisher
- Electric and manual bilge pump
Accessoires
- Folding gangway
- Boom cover
- Fenders
- Mooring lines
